8" Inch TFT-LCD Display

B080UAB01.0
AUO

Home
TFT-LCD
AUO
B080UAB01.0

8" Inch TFT-LCD Display
B080UAB01.0
AUO

Product description

B080UAB01.0 is a display manufactured by AUO. It has a resolution of 1200 x 1920, brightness of 350 cd/m2 and contrast of 900:1.

Available Stock

Condition: New Functionally never used, may come with original packaging
Available: 5084 units
Added: November 1, 2022
Updated: November 1, 2022

Enter Quantity

Electrical Specs

Backlight Location: Edge
Backlight: WLED
Lamp Lifetime (Time to Half Brightness): 15000
Backlight Voltage Minimum: 24
Backlight Voltage Typical: 24
Backlight Voltage Maximum: 24
Backlight Current Typical (mAh): 190
Maximum Backlight Consumption: 1.4
Backlight Driver Board: None
Backlight Connection: Embedded into Signal
Signal type: MIPI
Signal Channels: 4
VCC: 3.3
Maximum LCD Power Consumption: 0.45
Signal Interface: Connector
Signal Interface Connectors: 1
Signal Pins Quantity: 45

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1200 x 1920
Dot Pitch: 0.03
Dot pitch vertical: 0.09
Hardness: Hard coating (7H)
Reflection: No
Display Type: VA
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 350
Contrast: 900
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 60
Color Gamut Type: NTSC
Left Viewing Angle: 80
Top Viewing Angle: 80
Right Viewing Angle: 80
Bottom Viewing Angle: 80
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.3
Chromaticity: 0.32
light uniformity: 1.18/1.25 (Typ./Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: Assembly
Size: 8
Aspect Ratio: 10 x 16
Shape: Flat Rectangle
Vertical Active Area: 172.22
Outline Vertical: 206.6
Outline Depth Max: 3.4500
Orientation: Horizontal

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED
Simultaneous Touch Points: 10
Touchscreen Signal Type: I²C
Touchscreen Connection: Connector
Touchscreen Controller: With touch controller

Weights specs

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
