10.1" Inch TFT-LCD Display

CLAA101ND06CW
CPT

Home
TFT-LCD
CPT
CLAA101ND06CW

10.1" Inch TFT-LCD Display
CLAA101ND06CW
CPT

Product description

CLAA101ND06CW is a display manufactured by CPT. It has a resolution of 1024 x 600, brightness of 500 cd/m2 and contrast of 600:1.

Electrical Specs

Total Power Consumption (Watts): 3.16
Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 6S7P
Baklight Arrangement: Array
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 17.4
Backlight Voltage Typical: 17.4
Backlight Voltage Maximum: 17.4
Backlight Current Typical (mAh): 140
Typical Backlight Consumption: 2.68
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: JST
Backlight Interface Model: BHSR-02VS-1
Blu interface pin pitch mm: 3.5
Blu interface amount: 1
Blu interface pin amount: 2
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 1
Signal bits: 6/8-bit
LCD Signal AVDD: 9.6
LCD Signal VGH: 18
LCD Signal VGL: -6
LCD Signal VDD: 3.3
Maximum LCD Power Consumption: 0.62
Typical LCD Power Consumption: 0.48
Signal Interface: FPC
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 1
Signal Pins Quantity: 60
Signal Pins Configuration: LVDS-60P1C8B-010A

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1024 x 600
Dot Pitch: 0.07
Dot pitch vertical: 0.21
Glare: Antiglare
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 500
Contrast: 600
Colors: 262000
Display colors value 2: 16200000
Gray Scale: 6-bit
Gray method value 2: 6-bit + FRC
Gamut Percentage: 50
Color Gamut Type: NTSC
Left Viewing Angle: 70
Top Viewing Angle: 70
Right Viewing Angle: 70
Bottom Viewing Angle: 50
Optimal Viewing Direction: 6 o'clock
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.25/1.43 (Typ./Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: Yes
Reverse Scan Direction: Up/Down/Left/Right

Mechanical specs

Display Type: LCM
Size: 10.1
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 125.28
Bezel Height: 128.5
Outline Vertical: 143
Outline Depth Typical: 4.5
Outline Depth Max: 4.8000
Mounting: Without
Orientation: Vertical
Mounting Holes: Without

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 285
Typical Weight: 285
Maximum Weight: 285

Temperature Specs

Minimum Operating Temperature: -20
Maximum Operating Temperature: 70
Storage Temperature Minumum: -30
Storage Temperature Maximum: 80
