10.4" Inch TFT-LCD Display

G104X1-L02
Innolux

Home
TFT-LCD
Innolux
G104X1-L02

10.4" Inch TFT-LCD Display
G104X1-L02
Innolux

Product description

G104X1-L02 is a display manufactured by Innolux. It has a resolution of 1024 x 768, brightness of 400 cd/m2 and contrast of 1200:1.

Available Stock

Condition: New Functionally never used, may come with original packaging
Available: 300 units
Added: November 1, 2022
Updated: November 1, 2022

Enter Quantity

Electrical Specs

Backlight Location: Edge
Backlight: CCFL
Backlight Lamp Quantity: 2 pcs
Baklight Arrangement: Straight
Lamp Lifetime (Time to Half Brightness): 50000
Backlight Voltage Minimum: 460
Backlight Voltage Typical: 460
Backlight Voltage Maximum: 460
Backlight Current Minimum (mAh): -0.5
Backlight Current Typical (mAh): 7.6
Backlight Current Maximum (mAh): 8.1
Backlight Driver Board: None
Backlight Connection: via Connector
Signal type: LVDS
Signal Channels: 1
Signal bits: 8-bit
VCC: 3.3
Signal Interface: Connector

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1024 x 768
Dot Pitch: 0.07
Dot pitch vertical: 0.21
Glare: Glare
Hardness: Hard coating (3H)
Reflection: No
Display Type: VA
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 400
Contrast: 1200
Colors: 16200000
Gray Scale: 6-bit + FRC
Gamut Percentage: 57
Color Gamut Type: NTSC
Left Viewing Angle: 88
Top Viewing Angle: 88
Right Viewing Angle: 88
Bottom Viewing Angle: 88
Optimal Viewing Direction: Symmetrical
Response Time: 14
Response Time: 11
Chromaticity: 0.33
Chromaticity: 0.35
light uniformity: 1.40 (Max.)
(5 points)
Sunlight Readable: No
Reverse Scan: Yes
Reverse Scan Direction: 180 degrees

Mechanical specs

Display Type: LCM
Size: 10.4
Aspect Ratio: 4 x 3
Shape: Flat Rectangle
Vertical Active Area: 157.8
Bezel Height: 161.8
Outline Vertical: 176.3
Outline Depth Typical: 8.7
Outline Depth Max: 10.6700
Mounting: Side mounting holes (4-M2) on left, right bezel
Orientation: Vertical
Mounting Holes: Side mounting holes (4-M2) on left, right bezel

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 480
Typical Weight: 480
Maximum Weight: 480

Temperature Specs

Minimum Operating Temperature: -20
Maximum Operating Temperature: 70
Storage Temperature Minumum: -20
Storage Temperature Maximum: 80
