25.5" Inch TFT-LCD Display

G260JJE-L07
Innolux

Home
TFT-LCD
Innolux
G260JJE-L07

Innolux G260JJE-L07 - TFT-LCD 1920 x 1200

Product description

G260JJE-L07 is a display manufactured by Innolux. It has a resolution of 1920 x 1200, brightness of 350 cd/m2 and contrast of 1500:1.

Available Stock

Condition: New Functionally never used, may come with original packaging
Available: 100 units
Updated: November 1, 2022

Enter Quantity

Electrical Specs

Backlight Location: Direct
Backlight: WLED
Lamp Lifetime (Time to Half Brightness): 50000
Backlight Driver Board: With LED Driver
Minimum Voltage Driver Consumption: 21.6
Maximum Voltage Driver Consumption: 26.4
Minimum Backlight Consumption: 30
Maximum Backlight Consumption (Watts): 35
Backlight Connection: via Connector
Backlight Interface Manufacturer: FCN
Backlight Interface Model: JH2-D4-143N
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 14
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 2
Signal bits: 8-bit
VCC: 5
Signal Interface: Connector
Signal Interface Manufacturer: P-TWO
Signal Interface Model: 187114-30091
LCD Signal Interface Pins Pitch (mm): 1
Signal Interface Connectors: 1
Signal Pins Quantity: 30
Signal Pins Configuration: LVDS-30P2C8B-150A

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1200
Dot Pitch: 0.1
Dot pitch vertical: 0.29
Glare: Antiglare
Hardness: Hard coating (3H)
Reflection: No
Display Type: VA
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 350
Contrast: 1500
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 72
Color Gamut Type: NTSC
Left Viewing Angle: 88
Top Viewing Angle: 88
Right Viewing Angle: 88
Bottom Viewing Angle: 88
Optimal Viewing Direction: Symmetrical
Response Time: 15
Response Time: 5
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.40/1.50 (Typ./Max.)
(13 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 25.5
Aspect Ratio: 16 x 10
Shape: Flat Rectangle
Vertical Active Area: 343.8
Bezel Height: 347.8
Outline Vertical: 375.6
Outline Depth Typical: 30.1
Outline Depth Max: 30.6000
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 3750
Typical Weight: 3750
Maximum Weight: 3750

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
