10.1" Inch TFT-LCD Display

HJ101IA-01Q
Innolux

Home
TFT-LCD
Innolux
HJ101IA-01Q

10.1" Inch TFT-LCD Display
HJ101IA-01Q
Innolux

Product description

HJ101IA-01Q is a display manufactured by Innolux. It has a resolution of 1280 x 800, brightness of 330 cd/m2 and contrast of 720:1.

Electrical Specs

Backlight Location: Edge
Backlight: WLED
Lamp Lifetime (Time to Half Brightness): 15000
Backlight Voltage Minimum: 8.7
Backlight Voltage Typical: 8.7
Backlight Voltage Maximum: 8.7
Backlight Current Typical (mAh): 180
Backlight Driver Board: With LED Driver
Backlight Connection: Embedded into Signal
Signal type: LVDS
Signal Channels: 1
Signal bits: 8-bit
VCC: 3.3
Typical LCD Power Consumption: 0.91
Signal Interface: Connector
Signal Interface Manufacturer: Vigorconn
Signal Interface Model: L71240-00220PK
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 1
Signal Pins Quantity: 40
Signal Pins Configuration: LVDS-40P1C8B-060A

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1280 x 800
Dot Pitch: 0.06
Dot pitch vertical: 0.17
Glare: Antiglare
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 330
Contrast: 720
Colors: 16700000
Gray Scale: 8-bit
Left Viewing Angle: 80
Top Viewing Angle: 80
Right Viewing Angle: 80
Bottom Viewing Angle: 80
Optimal Viewing Direction: Symmetrical
Response Time: 10
Response Time: 15
Chromaticity: 0.33
Chromaticity: 0.37
light uniformity: 1.33/1.43 (Typ./Max.)
(13 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 10.1
Aspect Ratio: 16 x 10
Shape: Flat Rectangle
Vertical Active Area: 135.6
Bezel Height: 138.9
Outline Vertical: 149.1
Outline Depth Typical: 2.55
Outline Depth Max: 4.5600
Mounting: Face mounting holes (8 pcs) on left, right, up, down slugs
Orientation: Vertical
Mounting Holes: Face mounting holes (8 pcs) on left, right, up, down slugs

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 180
Typical Weight: 180
Maximum Weight: 180

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
