8.4" Inch TFT-LCD Display

LA084X02-SL01
LG Display

Home
TFT-LCD
LG Display
LA084X02-SL01

8.4" Inch TFT-LCD Display
LA084X02-SL01
LG Display

Product description

LA084X02-SL01 is a display manufactured by LG Display. It has a resolution of 1024 x 768, brightness of 1200 cd/m2 and contrast of 1000:1.

Available Stock

Condition: New Functionally never used, may come with original packaging
Available: 300 units
Added: November 1, 2022
Updated: November 1, 2022

Enter Quantity

Electrical Specs

Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 10S3P
Baklight Arrangement: 3 rows
Backlight Voltage Minimum: 27
Backlight Voltage Typical: 27
Backlight Voltage Maximum: 27
Backlight Current Minimum (mAh): 100
Backlight Current Typical (mAh): 105
Backlight Current Maximum (mAh): 105
Maximum Backlight Consumption: 10.7
Typical Backlight Consumption: 9
Backlight Driver Board: None
Backlight Connection: Embedded into Signal
Signal type: LVDS
Signal Channels: 1
Signal bits: 8-bit
VCC: 3.3
Maximum LCD Power Consumption: 1.78
Typical LCD Power Consumption: 1.45
Signal Interface: FPC
Signal Interface Connectors: 1
Signal Pins Quantity: 40

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1024 x 768
Dot Pitch: 0.06
Dot pitch vertical: 0.17
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 1200
Contrast: 1000
Colors: 16200000
Gray Scale: 8-bit
Gamut Percentage: 70
Color Gamut Type: NTSC
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.3
Chromaticity: 0.31
Sunlight Readable: Yes
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 8.4
Aspect Ratio: 4 x 3
Shape: Flat Rectangle
Vertical Active Area: 127.87
Outline Vertical: 143
Outline Depth Typical: 7.25
Outline Depth Max: 9.9500
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 257.5
Typical Weight: 257.5
Maximum Weight: 257.5

Temperature Specs

Minimum Operating Temperature: -40
Maximum Operating Temperature: 85
Storage Temperature Minumum: -40
Storage Temperature Maximum: 90
