LG Display LC170WXN-SAA1 - TFT-LCD 1366 x 768

Product description

LC170WXN-SAA1 is a display manufactured by LG Display. It has a resolution of 1366 x 768, brightness of 350 cd/m2 and contrast of 900:1.

Electrical Specs

Total Power Consumption (Watts): 36.1
Backlight Location: Direct
Backlight: EEFL
Backlight Lamp Quantity: 8 pcs
Lamp Lifetime (Time to Half Brightness): 50000
Backlight Driver Board: With Inverter
Minimum Backlight Consumption: 33.6
Maximum Backlight Consumption (Watts): 38.4
Backlight Connection: via Connector
Backlight Interface Manufacturer: JST
Backlight Interface Model: S14B-PH-SM3-TB
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 14
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 1
Signal bits: 8-bit
VCC: 12
Maximum LCD Power Consumption: 3
Typical LCD Power Consumption: 2.5
Signal Interface: Connector
Signal Interface Manufacturer: JAE
Signal Interface Model: FI-X30SSL-HF
LCD Signal Interface Pins Pitch (mm): 1
Signal Interface Connectors: 1
Signal Pins Quantity: 30
Signal Pins Configuration: LVDS-30P1C8B-020D

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1366 x 768
Dot Pitch: 0.09
Dot pitch vertical: 0.27
Glare: Antiglare
Glare: 13
Hardness: Hard coating (3H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 350
Contrast: 900
Colors: 16700000
Gray Scale: 8-bit
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Response Time: 8
Response Time: 9
Chromaticity: 0.27
Chromaticity: 0.29
light uniformity: 1.30 (Max.)
(5 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 17
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 209.66
Bezel Height: 213.8
Outline Vertical: 252
Outline Depth Typical: 43.6
Mounting: Side mounting holes (4-M3)
Orientation: Vertical
Mounting Holes: Side mounting holes (4-M3)

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 2155
Typical Weight: 2155
Maximum Weight: 2155

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
