42" Inch TFT-LCD Display

LC420EUS-SCA2
LG Display

Home
TFT-LCD
LG Display
LC420EUS-SCA2

LG Display LC420EUS-SCA2 - TFT-LCD 1920 x 1080 Full HD

Product description

LC420EUS-SCA2 is a display manufactured by LG Display. It has a resolution of 1920 x 1080, brightness of 450 cd/m2 and contrast of 1300:1.

Electrical Specs

Total Power Consumption (Watts): 111.2
Backlight Location: Edge
Backlight: WLED
Baklight Arrangement: 6 rows × 2CN
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 118.2
Backlight Voltage Typical: 118.2
Backlight Voltage Maximum: 118.2
Backlight Current Typical (mAh): 165
Maximum Backlight Consumption: 84.8
Typical Backlight Consumption: 81.4
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: YEONHO
Backlight Interface Model: 20010HS-13B(BK), 20010HS-12
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 13
Blu interface pin configuration: 0
Signal type: Mini LVDS
VCC: 12
Typical LCD Power Consumption: 18.7
Signal Interface: Connector
Signal Interface Manufacturer: HRS
Signal Interface Model: TF06L-80S-0.5SH
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 2
Signal Pins Quantity: 80

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.16
Dot pitch vertical: 0.48
Glare: Antiglare
Glare: 10
Hardness: Hard coating (2H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 450
Contrast: 1300
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 72
Color Gamut Type: NTSC
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Response Time: 6
Response Time: 6
Chromaticity: 0.28
Chromaticity: 0.29
light uniformity: 1.30 (Max.)
(5 points)
3D Type: 3D (Shutter Glass)
Sunlight Readable: No

Mechanical specs

Display Type: LCM
Size: 42
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 523.26
Bezel Height: 530.2
Outline Vertical: 566.2
Outline Depth Typical: 25.3
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 11100
Typical Weight: 11100
Maximum Weight: 11100

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
