55" Inch TFT-LCD Display

LC550EUB-SCA1
LG Display

Home
TFT-LCD
LG Display
LC550EUB-SCA1

55" Inch TFT-LCD Display
LC550EUB-SCA1
LG Display

Product description

LC550EUB-SCA1 is a display manufactured by LG Display. It has a resolution of 1920 x 1080, brightness of 450 cd/m2 and contrast of 1400:1.

Electrical Specs

Vertical frequency hz input signal: 120
Vertical frequency hz display output: 120
Total Power Consumption (Watts): 142.3
Backlight Location: Edge
Backlight: WLED
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Driver Board: With LED Driver
Minimum Voltage Driver Consumption: 22.8
Maximum Voltage Driver Consumption: 25.2
Minimum Backlight Consumption: 134.4
Maximum Backlight Consumption (Watts): 142.8
Backlight Connection: via Connector
Backlight Interface Manufacturer: YEONHO
Backlight Interface Model: 20022WR-14B1, 12507WR-08L
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 14
Blu interface pin configuration: 0
Signal type: Mini LVDS
VCC: 3.3
LCD Signal VGH: 28
LCD Signal VGL: -5.3
LCD Signal VDD: 16.3
Maximum LCD Power Consumption: 10.7
Typical LCD Power Consumption: 8.3
Signal Interface: Connector
Signal Interface Manufacturer: HRS
Signal Interface Model: TF06L-60S-0.5SH
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 2
Signal Pins Quantity: 60

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.21
Dot pitch vertical: 0.63
Glare: Antiglare
Glare: 10
Hardness: Hard coating (3H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 450
Contrast: 1400
Colors: 16700000
Gray Scale: 8-bit
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Response Time: 8
Response Time: 10
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 55
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 680.4
Bezel Height: 688.4
Outline Vertical: 732.4
Outline Depth Typical: 24.2
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 22000
Typical Weight: 22000
Maximum Weight: 22000

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
