55" Inch TFT-LCD Display

LC550WUD-SBM4
LG Display

Home
TFT-LCD
LG Display
LC550WUD-SBM4

55" Inch TFT-LCD Display
LC550WUD-SBM4
LG Display

Product description

LC550WUD-SBM4 is a display manufactured by LG Display. It has a resolution of 1920 x 1080, brightness of 590 cd/m2 and contrast of 1300:1.

Electrical Specs

Vertical frequency hz input signal: 120
Vertical frequency hz display output: 120
Total Power Consumption (Watts): 249.5
Backlight Location: Direct
Backlight: CCFL
Lamp Lifetime (Time to Half Brightness): 50000
Backlight Driver Board: With Inverter
Minimum Backlight Consumption: 242
Maximum Backlight Consumption (Watts): 266
Backlight Connection: via Connector
Signal type: LVDS
Signal Channels: 4
Signal bits: 8/10-bit
VCC: 12
Maximum LCD Power Consumption: 9.75
Typical LCD Power Consumption: 7.5
Signal Interface: Connector

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.21
Dot pitch vertical: 0.63
Glare: Antiglare
Glare: 10
Hardness: Hard coating (3H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 590
Contrast: 1300
Colors: 16700000
Gray Scale: 8-bit
Gray method value 2: 8-bit + Dithering
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.28
Chromaticity: 0.29
light uniformity: 1.30 (Max.)
(5 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 55
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 680.4
Bezel Height: 688.4
Outline Vertical: 718.4
Outline Depth Typical: 19.5
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 19950
Typical Weight: 19950
Maximum Weight: 19950

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
