Product description

LC600DUF-FGF1 is a display manufactured by LG Display. It has a resolution of 1920 x 1080, brightness of 450 cd/m2 and contrast of 1400:1.

Electrical Specs

Total Power Consumption (Watts): 87.58
Backlight Location: Direct
Backlight: WLED
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 67.1
Backlight Voltage Typical: 67.1
Backlight Voltage Maximum: 67.1
Backlight Current Typical (mAh): 200
Maximum Backlight Consumption: 94
Typical Backlight Consumption: 83
Backlight Driver Board: None
Backlight Connection: via Connector
Signal type: LVDS
Signal Channels: 4
Signal bits: 8/10-bit
VCC: 12
Maximum LCD Power Consumption: 5.96
Typical LCD Power Consumption: 4.58
Signal Interface: Connector

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.23
Dot pitch vertical: 0.69
Glare: Antiglare
Glare: 1
Hardness: Hard coating (2H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 450
Contrast: 1400
Colors: 16700000
Gray Scale: 8-bit
Gray method value 2: 8-bit + Dithering
Gamut Percentage: 68
Color Gamut Type: NTSC
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.28
Chromaticity: 0.29
light uniformity: 1.30 (Max.)
(9 points)
3D Type: 3D (Polarizer Glass)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 60
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 740.6
Bezel Height: 748
Outline Vertical: 780.54
Outline Depth Max: 41.0000
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 17150
Typical Weight: 17150
Maximum Weight: 17150

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
