LG Display LD490EUN-UHA3 - TFT-LCD 1920 x 1080 Full HD

Product description

LD490EUN-UHA3 is a display manufactured by LG Display. It has a resolution of 1920 x 1080, brightness of 700 cd/m2 and contrast of 1300:1.

Electrical Specs

Vertical frequency hz display output: 60
Total Power Consumption (Watts): 99.6
Backlight Location: Edge light type
Backlight: WLED
Backlight Lamp Quantity: 1 pcs
Backlight Driver Board: With LED Driver
Minimum Voltage Driver Consumption: 21.6
Maximum Voltage Driver Consumption: 26.4
Minimum Current Driver Consumption: 3.79
Minimum Current Driver Consumption: 4.17
Minimum Backlight Consumption: 90.9
Maximum Backlight Consumption (Watts): 100.1
Backlight Connection: via Connector
Backlight Interface Manufacturer: YEONHO
Backlight Interface Model: 20022WR-H14B2
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 14
Signal type: LVDS
Signal Channels: 2
Signal bits: 8/10-bit
VCC: 12
Maximum LCD Power Consumption: 11.3
Typical LCD Power Consumption: 8.7
Signal Interface: Connector
Signal Interface Manufacturer: JAE
Signal Interface Model: FI-RE51S-HF
Signal Interface Connectors: 1

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.19
Dot pitch vertical: 0.56
Glare: Antiglare
Glare: 10
Hardness: Hard coating (3H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 700
Contrast: 1300
Colors: 16700000
Gray Scale: 8-bit
Gray method value 2: 8-bit + Dithering
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.29
Sunlight Readable: Yes
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 49
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 604
Bezel Height: 610
Outline Vertical: 621.8
Outline Depth Typical: 19
Outline Depth Max: 34.7000
Orientation: Vertical / Horizontal
Bezel Thickness: 17.8

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 11900
Typical Weight: 11900
Maximum Weight: 11900

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
