LG Display LM185WH2-TLD1 - TFT-LCD 1366 x 768

Product description

LM185WH2-TLD1 is a display manufactured by LG Display. It has a resolution of 1366 x 768, brightness of 200 cd/m2 and contrast of 600:1.

Electrical Specs

Total Power Consumption (Watts): 10.4
Backlight Location: Edge (Right side)
Backlight: WLED
Backlight Lamp Quantity: 11S2P
Baklight Arrangement: 2 rows
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 32.9
Backlight Voltage Typical: 34.1
Backlight Voltage Maximum: 35.3
Backlight Current Minimum (mAh): 100
Backlight Current Typical (mAh): 115
Backlight Current Maximum (mAh): 115
Maximum Backlight Consumption: 7.3
Typical Backlight Consumption: 6.8
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: JST
Backlight Interface Model: SM06B-SHJH(HF)
Blu interface pin pitch mm: 1
Blu interface amount: 1
Blu interface pin amount: 6
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 1
Signal bits: 8-bit
VCC: 5
Maximum LCD Power Consumption: 4.7
Typical LCD Power Consumption: 3.6
Signal Interface: Connector
Signal Interface Manufacturer: LS Mtron
Signal Interface Model: GT103-30S-HF15-E2500
LCD Signal Interface Pins Pitch (mm): 1
Signal Interface Connectors: 1
Signal Pins Quantity: 30
Signal Pins Configuration: LVDS-30P1C8B-170K

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1366 x 768
Dot Pitch: 0.1
Dot pitch vertical: 0.3
Glare: Antiglare
Hardness: Hard coating (3H)
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 200
Contrast: 600
Colors: 16700000
Gray Scale: 6-bit + Hi-FRC
Left Viewing Angle: 45
Top Viewing Angle: 45
Right Viewing Angle: 15
Bottom Viewing Angle: 35
Optimal Viewing Direction: 6 o'clock
Response Time: 1.1
Response Time: 3.9
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.50 (Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 18.5
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 230.4
Bezel Height: 234
Outline Vertical: 254.6
Outline Depth Typical: 8.6
Outline Depth Max: 10.7000
Mounting: Side mounting holes (4-M3) on left, right bezel
Orientation: Vertical
Mounting Holes: Side mounting holes (4-M3) on left, right bezel

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 1385
Typical Weight: 1385
Maximum Weight: 1385

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
