LG Display LM230WF7-SSB1 - TFT-LCD 1920 x 1080 Full HD

Product description

LM230WF7-SSB1 is a display manufactured by LG Display. It has a resolution of 1920 x 1080, brightness of 250 cd/m2 and contrast of 1000:1.

Electrical Specs

Total Power Consumption (Watts): 12.78
Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 14S4P
Baklight Arrangement: 4 rows
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 38.8
Backlight Voltage Typical: 41.6
Backlight Voltage Maximum: 44.4
Backlight Current Minimum (mAh): 60
Backlight Current Typical (mAh): 65
Backlight Current Maximum (mAh): 65
Maximum Backlight Consumption: 10.7
Typical Backlight Consumption: 10
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: JST
Backlight Interface Model: SM06B-SHJH(HF)
Blu interface pin pitch mm: 1
Blu interface amount: 1
Blu interface pin amount: 6
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 2
Signal bits: 8-bit
VCC: 5
Maximum LCD Power Consumption: 3.19
Typical LCD Power Consumption: 2.78
Signal Interface: Connector
Signal Interface Manufacturer: UJU
Signal Interface Model: IS100-L30B-C23
LCD Signal Interface Pins Pitch (mm): 1
Signal Interface Connectors: 1
Signal Pins Quantity: 30

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.09
Dot pitch vertical: 0.27
Glare: Antiglare
Hardness: Hard coating (3H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 250
Contrast: 1000
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 72
Color Gamut Type: NTSC
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.33 (Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 23
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 286.42
Outline Vertical: 302.8
Outline Depth Typical: 8.55
Outline Depth Max: 12.7000
Mounting: Rear mounting holes (9-M3)
Orientation: Vertical
Mounting Holes: Rear mounting holes (9-M3)

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED
Simultaneous Touch Points: 10
Touchscreen Signal Type: USB
Touchscreen Connection: Connector
Touchscreen Controller: With touch controller

Weights specs

Minimum Weight: 1810
Typical Weight: 1810
Maximum Weight: 1810

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
