LG Display LM270WQ1-SLC2 - TFT-LCD 2560 x 1440 Quad HD

Product description

LM270WQ1-SLC2 is a display manufactured by LG Display. It has a resolution of 2560 x 1440, brightness of 350 cd/m2 and contrast of 1000:1.

Electrical Specs

Total Power Consumption (Watts): 34.94
Backlight Location: Edge (Bottom side)
Backlight: WLED
Backlight Lamp Quantity: 17S4P
Baklight Arrangement: 4 rows
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 50.2
Backlight Voltage Typical: 53.6
Backlight Voltage Maximum: 57
Backlight Current Minimum (mAh): 120
Backlight Current Typical (mAh): 125
Backlight Current Maximum (mAh): 125
Maximum Backlight Consumption: 27.3
Typical Backlight Consumption: 25.7
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: JST
Backlight Interface Model: SM06B-SHJH(HF)
Blu interface pin pitch mm: 1
Blu interface amount: 1
Blu interface pin amount: 6
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 4
Signal bits: 10-bit
VCC: 12
Maximum LCD Power Consumption: 16.38
Typical LCD Power Consumption: 12.6
Signal Interface: Connector
Signal Interface Manufacturer: JAE
Signal Interface Model: FI-RE51S-HF
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 1
Signal Pins Quantity: 51

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 2560 x 1440
Dot Pitch: 0.08
Dot pitch vertical: 0.23
Glare: Antiglare
Hardness: Hard coating (3H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 350
Contrast: 1000
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 100
Color Gamut Type: sRGB
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.43 (Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 27
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 335.66
Bezel Height: 340.4
Outline Vertical: 368.2
Outline Depth Typical: 8.7
Outline Depth Max: 15.4000
Mounting: Side mounting holes (4-M3) on left, right bezel
Orientation: Vertical
Mounting Holes: Side mounting holes (4-M3) on left, right bezel

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 2685
Typical Weight: 2685
Maximum Weight: 2685

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
