LG Display LM300W01-STA1 - TFT-LCD 2560 x 1600

Product description

LM300W01-STA1 is a display manufactured by LG Display. It has a resolution of 2560 x 1600, brightness of 370 cd/m2 and contrast of 600:1.

Electrical Specs

Total Power Consumption (Watts): 99.5
Backlight Location: Direct
Backlight: CCFL
Backlight Lamp Quantity: 16 pcs
Baklight Arrangement: Straight
Lamp Lifetime (Time to Half Brightness): 50000
Backlight Driver Board: With Inverter
Backlight Connection: via Connector
Backlight Interface Manufacturer: JST
Backlight Interface Model: S14B-PH-SM3-TB
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 14
Blu interface pin configuration: 0
Signal type: Dual Link TMDS
VCC: 18
Typical LCD Power Consumption: 11.5
Signal Interface: Connector
Signal Interface Manufacturer: HRS
Signal Interface Model: KDF71G-30S-1H
LCD Signal Interface Pins Pitch (mm): 1
Signal Interface Connectors: 1
Signal Pins Quantity: 30

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 2560 x 1600
Dot Pitch: 0.08
Dot pitch vertical: 0.25
Glare: Antiglare
Glare: 13
Hardness: Hard coating (3H)
Reflection: No
Display Type: IPS
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 370
Contrast: 600
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 72
Color Gamut Type: NTSC
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Response Time: 8
Response Time: 6
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.43 (Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 30
Aspect Ratio: 16 x 10
Shape: Flat Rectangle
Vertical Active Area: 400.8
Bezel Height: 405.8
Outline Vertical: 436.8
Outline Depth Typical: 42.3
Mounting: Side mounting holes; Rear mounting holes
Orientation: Vertical
Mounting Holes: Side mounting holes; Rear mounting holes

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 5100
Typical Weight: 5100
Maximum Weight: 5100

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
