13.3" Inch TFT-LCD Display
LP133WX2-TLG5
LG Display

Product description

LP133WX2-TLG5 is a display manufactured by LG Display. It has a resolution of 1280 x 800, brightness of 275 cd/m2 and contrast of 600:1.

Electrical Specs

Total Power Consumption (Watts): 3.96
Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 9S6P
Baklight Arrangement: 6 rows
Lamp Lifetime (Time to Half Brightness): 10000
Backlight Current Minimum (mAh): 5
Backlight Current Typical (mAh): 19
Backlight Current Maximum (mAh): 20
Maximum Backlight Consumption: 3.5
Typical Backlight Consumption: 3.2
Backlight Driver Board: None
Backlight Connection: Embedded into Signal
Signal type: LVDS
Signal Channels: 1
Signal bits: 6-bit
VCC: 3.3
Typical LCD Power Consumption: 0.76
Signal Interface: Connector
Signal Interface Manufacturer: I-PEX
Signal Interface Model: 20474-030E-12
LCD Signal Interface Pins Pitch (mm): 0.4
Signal Interface Connectors: 1
Signal Pins Quantity: 30
Signal Pins Configuration: LVDS-30P1C6B-070B

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1280 x 800
Dot Pitch: 0.07
Dot pitch vertical: 0.22
Glare: Glare
Hardness: Hard coating (2H)
Reflection: Yes
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 275
Contrast: 600
Colors: 262000
Gray Scale: 6-bit
Gamut Percentage: 50
Color Gamut Type: NTSC
Left Viewing Angle: 70
Top Viewing Angle: 70
Right Viewing Angle: 60
Bottom Viewing Angle: 60
Optimal Viewing Direction: 6 o'clock
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.43/1.67 (Typ./Max.)
(160 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 13.3
Aspect Ratio: 16 x 10
Shape: Flat Rectangle
Vertical Active Area: 178.8
Bezel Height: 182.5
Outline Vertical: 203.1
Outline Depth Max: 3.6800
Mounting: Face mounting holes (4 pcs) on left, right slugs
Orientation: Vertical
Mounting Holes: Face mounting holes (4 pcs) on left, right slugs

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 310
Typical Weight: 310
Maximum Weight: 310

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
