LG Display LP154WP2-TLC2 - TFT-LCD 1440 x 900

Product description

LP154WP2-TLC2 is a display manufactured by LG Display. It has a resolution of 1440 x 900, brightness of 300 cd/m2 and contrast of 600:1.

Electrical Specs

Total Power Consumption (Watts): 4.6
Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 10S6P
Baklight Arrangement: 6 rows
Lamp Lifetime (Time to Half Brightness): 10000
Backlight Current Minimum (mAh): 5
Backlight Current Typical (mAh): 19
Backlight Current Maximum (mAh): 20
Maximum Backlight Consumption: 3.9
Typical Backlight Consumption: 3.6
Backlight Driver Board: With LED Driver
Backlight Connection: Embedded into Signal
Signal type: LVDS
Signal Channels: 2
Signal bits: 6-bit
VCC: 3.3
Maximum LCD Power Consumption: 1.44
Typical LCD Power Consumption: 0.99
Signal Interface: Connector
Signal Interface Manufacturer: JAE
Signal Interface Model: FI-VHP50S-A-HF11
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 1
Signal Pins Quantity: 50
Signal Pins Configuration: LVDS-50P2C6B-010A

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1440 x 900
Dot Pitch: 0.08
Dot pitch vertical: 0.23
Glare: Glare
Hardness: Hard coating (3H)
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 300
Contrast: 600
Colors: 262000
Gray Scale: 6-bit
Gamut Percentage: 45
Color Gamut Type: NTSC
Left Viewing Angle: 70
Top Viewing Angle: 70
Right Viewing Angle: 55
Bottom Viewing Angle: 65
Optimal Viewing Direction: 6 o'clock
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.60 (Max.)
(13 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 15.4
Aspect Ratio: 16 x 10
Shape: Flat Rectangle
Vertical Active Area: 207.09
Bezel Height: 210.4
Outline Vertical: 222
Outline Depth Max: 6.1000
Mounting: Side mounting holes (8-M2) on left, right bezel
Orientation: Vertical
Mounting Holes: Side mounting holes (8-M2) on left, right bezel

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 460
Typical Weight: 460
Maximum Weight: 460

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
