17.1" Inch TFT-LCD Display

LP171WU1-TLA2
LG Display

Home
TFT-LCD
LG Display
LP171WU1-TLA2

17.1" Inch TFT-LCD Display
LP171WU1-TLA2
LG Display

Product description

LP171WU1-TLA2 is a display manufactured by LG Display. It has a resolution of 1920 x 1200, brightness of 260 cd/m2 and contrast of 500:1.

Electrical Specs

Total Power Consumption (Watts): 6.99
Backlight Location: Edge (Bottom side)
Backlight: CCFL
Backlight Lamp Quantity: 1 pcs
Baklight Arrangement: Straight
Lamp Lifetime (Time to Half Brightness): 15000
Backlight Voltage Minimum: 710
Backlight Voltage Typical: 710
Backlight Voltage Maximum: 710
Backlight Current Minimum (mAh): 3
Backlight Current Typical (mAh): 6.5
Backlight Current Maximum (mAh): 6.8
Backlight Operation Frequency: 60
Maximum Backlight Consumption: 5.26
Typical Backlight Consumption: 4.84
Backlight Driver Board: None
Backlight Connection: via Connector
Signal type: LVDS
Signal Channels: 2
Signal bits: 6-bit
VCC: 3.3
Maximum LCD Power Consumption: 2.7
Typical LCD Power Consumption: 2.15
Signal Interface: Connector

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1200
Dot Pitch: 0.06
Dot pitch vertical: 0.19
Glare: Glare
Hardness: Hard coating (4H)
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 260
Contrast: 500
Colors: 262000
Gray Scale: 6-bit
Gamut Percentage: 50
Color Gamut Type: NTSC
Left Viewing Angle: 65
Top Viewing Angle: 65
Right Viewing Angle: 55
Bottom Viewing Angle: 55
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 2.00 (Max.)
(13 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 17.1
Aspect Ratio: 16 x 10
Shape: Flat Rectangle
Vertical Active Area: 229.5
Bezel Height: 232.9
Outline Vertical: 267.2
Outline Depth Max: 6.6000
Mounting: Side mounting holes (8-M2) on left, right bezel; Face mounting holes (4 pcs) on up, down slugs
Orientation: Vertical
Mounting Holes: Side mounting holes (8-M2) on left, right bezel; Face mounting holes (4 pcs) on up, down slugs

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 690
Typical Weight: 690
Maximum Weight: 690

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
