Samsung LTA550HJ15 - TFT-LCD 1920 x 1080 Full HD

Product description

LTA550HJ15 is a display manufactured by Samsung. It has a resolution of 1920 x 1080, brightness of 350 cd/m2 and contrast of 5000:1.

Electrical Specs

Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 6 strings
Lamp Lifetime (Time to Half Brightness): 35000
Backlight Voltage Minimum: 70.3
Backlight Voltage Typical: 70.3
Backlight Voltage Maximum: 70.3
Backlight Current Minimum (mAh): 137.75
Backlight Current Typical (mAh): 145
Backlight Current Maximum (mAh): 152.25
Minimum Backlight Consumption: 61.1
Maximum Backlight Consumption: 69.5
Typical Backlight Consumption: 65.3
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: YEONHO
Backlight Interface Model: SMH200-10
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 10
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 4
Signal bits: 10-bit
VCC: 12
Signal Interface: Connector
Signal Interface Manufacturer: JAE
Signal Interface Model: FI-RE51S-HF
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 1
Signal Pins Quantity: 51

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.21
Dot pitch vertical: 0.63
Glare: Antiglare
Glare: 2
Hardness: Hard coating (2H)
Reflection: No
Display Type: VA
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 350
Contrast: 5000
Colors: 16700000
Gray Scale: 8-bit
Gray method value 2: 8-bit + Dithering
Gamut Percentage: 70
Color Gamut Type: NTSC
Left Viewing Angle: 89
Top Viewing Angle: 89
Right Viewing Angle: 89
Bottom Viewing Angle: 89
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.28
Chromaticity: 0.29
light uniformity: 1.33 (Max.)
(9 points)
3D Type: 3D (Shutter Glass)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 55
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 680.4
Bezel Height: 688.4
Outline Vertical: 711.3
Outline Depth Typical: 15.1
Outline Depth Max: 27.9000
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 18500
Typical Weight: 18500
Maximum Weight: 18500

Temperature Specs

Minimum Operating Temperature: -20
Maximum Operating Temperature: 70
Storage Temperature Minumum: -30
Storage Temperature Maximum: 80
