20" Inch TFT-LCD Display

LTM200KT10
Samsung

Home
TFT-LCD
Samsung
LTM200KT10

20" Inch TFT-LCD Display
LTM200KT10
Samsung

Product description

LTM200KT10 is a display manufactured by Samsung. It has a resolution of 1600 x 900, brightness of 250 cd/m2 and contrast of 1000:1.

Electrical Specs

Backlight Location: Edge (Right side)
Backlight: WLED
Backlight Lamp Quantity: 8S3P
Baklight Arrangement: 3 rows
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 25.6
Backlight Voltage Typical: 25.6
Backlight Voltage Maximum: 25.6
Backlight Current Typical (mAh): 120
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: molex
Backlight Interface Model: 104086-0410
Blu interface pin pitch mm: 1.25
Blu interface amount: 1
Blu interface pin amount: 4
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 2
Signal bits: 8-bit
VCC: 5
Signal Interface: Connector
Signal Interface Manufacturer: UJU
Signal Interface Model: IS100-L30O-C23
LCD Signal Interface Pins Pitch (mm): 1
Signal Interface Connectors: 1
Signal Pins Quantity: 30
Signal Pins Configuration: LVDS-30P2C8B-160A

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1600 x 900
Dot Pitch: 0.09
Dot pitch vertical: 0.28
Glare: Antiglare
Glare: 25
Hardness: Hard coating (3H)
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 250
Contrast: 1000
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 72
Color Gamut Type: NTSC
Left Viewing Angle: 80
Top Viewing Angle: 80
Right Viewing Angle: 80
Bottom Viewing Angle: 80
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.33 (Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 20
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 249.08
Bezel Height: 253.2
Outline Vertical: 272
Outline Depth Max: 10.3000
Mounting: Side mounting holes (4-M3) on left, right bezel
Orientation: Vertical
Mounting Holes: Side mounting holes (4-M3) on left, right bezel

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 1700
Typical Weight: 1700
Maximum Weight: 1700

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -25
Storage Temperature Maximum: 60
