24" Inch TFT-LCD Display

M240HTN01.1
AUO

Home
TFT-LCD
AUO
M240HTN01.1

24" Inch TFT-LCD Display
M240HTN01.1
AUO

Product description

M240HTN01.1 is a display manufactured by AUO. It has a resolution of 1920 x 1080, brightness of 200 cd/m2 and contrast of 600:1.

Available Stock

Condition: New Functionally never used, may come with original packaging
Available: 18 units
Added: November 1, 2022
Updated: November 1, 2022

Enter Quantity

Electrical Specs

Total Power Consumption (Watts): 15.8
Backlight Location: Edge (Right side)
Backlight: WLED
Backlight Lamp Quantity: 8S4P
Baklight Arrangement: 4 rows
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 25.6
Backlight Voltage Typical: 25.6
Backlight Voltage Maximum: 25.6
Backlight Current Minimum (mAh): 120
Backlight Current Typical (mAh): 126
Backlight Current Maximum (mAh): 126
Maximum Backlight Consumption: 13.7
Typical Backlight Consumption: 12.3
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: E&T
Backlight Interface Model: 3707K-S06N-07L
Blu interface pin pitch mm: 1
Blu interface amount: 1
Blu interface pin amount: 6
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 2
Signal bits: 8-bit
VCC: 5
Maximum LCD Power Consumption: 4.8
Typical LCD Power Consumption: 4
Signal Interface: Connector
Signal Interface Manufacturer: JAE
Signal Interface Model: FI-XPB30SRLA-HF11
LCD Signal Interface Pins Pitch (mm): 1
Signal Interface Connectors: 1
Signal Pins Quantity: 30
Signal Pins Configuration: LVDS-30P2C8B-160A

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.09
Dot pitch vertical: 0.28
Glare: Antiglare
Hardness: Hard coating (3H)
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 200
Contrast: 600
Colors: 16700000
Gray Scale: 6-bit + Hi-FRC
Left Viewing Angle: 45
Top Viewing Angle: 45
Right Viewing Angle: 20
Bottom Viewing Angle: 45
Optimal Viewing Direction: 6 o'clock
Response Time: 3.5
Response Time: 1.5
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.25/1.33 (Typ./Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 24
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 298.89
Bezel Height: 303
Outline Vertical: 323.2
Outline Depth Typical: 9.1
Outline Depth Max: 12.0000
Mounting: Side mounting holes (2-M3) on left bezel
Orientation: Vertical
Mounting Holes: Side mounting holes (2-M3) on left bezel

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 2020
Typical Weight: 2020
Maximum Weight: 2020

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
