30" Inch TFT-LCD Display

NL328204AC19-01
NLT

Home
TFT-LCD
NLT
NL328204AC19-01

30" Inch TFT-LCD Display
NL328204AC19-01
NLT

Product description

NL328204AC19-01 is a display manufactured by NLT. It has a resolution of 3280 x 2048, brightness of 1000 cd/m2 and contrast of 1500:1.

Electrical Specs

Total Power Consumption (Watts): 114
Backlight Location: Direct
Backlight: WLED
Backlight Driver Board: With LED Driver
Signal type: eDP

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 3280 x 2048
Dot Pitch: 0.07
Dot pitch vertical: 0.2
Glare: Antiglare
Reflection: No
Display Type: SFT
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 1000
Contrast: 1500
Gray Scale: 10-bit
Gamut Percentage: 72
Color Gamut Type: NTSC
Left Viewing Angle: 88
Top Viewing Angle: 88
Right Viewing Angle: 88
Bottom Viewing Angle: 88
Optimal Viewing Direction: Symmetrical
Sunlight Readable: Yes

Mechanical specs

Display Type: LCM
Size: 30
Aspect Ratio: 16 x 10
Shape: Flat Rectangle
Vertical Active Area: 403.05
Outline Vertical: 427
Outline Depth Max: 30.5000
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 5500
Typical Weight: 5500
Maximum Weight: 5500

Temperature Specs

Maximum Operating Temperature: 60
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
