Innolux TJ123NP01BA - TFT-LCD 1280 x 480

Product description

TJ123NP01BA is a display manufactured by Innolux. It has a resolution of 1280 x 480, brightness of 600 cd/m2 and contrast of 700:1.

Electrical Specs

Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 4 strings
Baklight Arrangement: 4 rows
Backlight Voltage Minimum: 10.8
Backlight Voltage Typical: 10.8
Backlight Voltage Maximum: 10.8
Typical Backlight Consumption: 4.96
Backlight Driver Board: None
Backlight Connection: via FPC Flex Cable
Signal type: TTL/RSDS
Signal Channels: 1
Signal bits: 6-bit
VCC: 3.3
Signal Interface: FPC

Optical specs

Panel type: TFT-LCD
Panel type child: LTPS
Resolution: 1280 x 480
Dot Pitch: 0.08
Dot pitch vertical: 0.23
Glare: Antiglare
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 600
Contrast: 700
Colors: 262000
Gray Scale: 6-bit
Gamut Percentage: 55
Color Gamut Type: NTSC
Left Viewing Angle: 60
Top Viewing Angle: 60
Right Viewing Angle: 55
Bottom Viewing Angle: 55
Optimal Viewing Direction: 12 o'clock
Response Time: 5
Response Time: 15
Chromaticity: 0.31
Chromaticity: 0.33
light uniformity: 1.18/1.25 (Typ./Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 12.3
Aspect Ratio: 8 x 3
Shape: Flat Rectangle
Vertical Active Area: 109.44
Bezel Height: 112
Outline Vertical: 134.6
Outline Depth Typical: 10
Outline Depth Max: 44.1000
Mounting: Face mounting holes (4 pcs) on left, right slugs
Orientation: Vertical
Mounting Holes: Face mounting holes (4 pcs) on left, right slugs

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 800
Typical Weight: 800
Maximum Weight: 800

Temperature Specs

Minimum Operating Temperature: -30
Maximum Operating Temperature: 85
Storage Temperature Minumum: -40
Storage Temperature Maximum: 90
