5.7" Inch TFT-LCD Display
TM057KDH01
Tianma

Product description

TM057KDH01 is a display manufactured by Tianma. It has a resolution of 320 x 240, brightness of 400 cd/m2 and contrast of 500:1.

Electrical Specs

Backlight Location: Edge
Backlight: WLED
Backlight Lamp Quantity: 5S3P
Baklight Arrangement: 3 rows
Lamp Lifetime (Time to Half Brightness): 50000
Backlight Voltage Minimum: 14.85
Backlight Voltage Typical: 14.85
Backlight Voltage Maximum: 14.85
Backlight Current Typical (mAh): 25
Typical Backlight Consumption: 1.24
Backlight Driver Board: None
Backlight Connection: via Connector
Backlight Interface Manufacturer: JST
Backlight Interface Model: SHLP-06V-S-B
Blu interface pin pitch mm: 1
Blu interface amount: 1
Blu interface pin amount: 6
Blu interface pin configuration: 0
Signal type: Parallel RGB
Signal Channels: 1
Signal bits: 6-bit
VCC: 3.3
Signal Interface: Connector
Signal Interface Manufacturer: STARCONN
Signal Interface Model: 089H33-000100-G2-R
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 1
Signal Pins Quantity: 33
Signal Pins Configuration: DRGB-33P1C6B-020B

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 320 x 240
Dot Pitch: 0.12
Dot pitch vertical: 0.36
Glare: Antiglare
Hardness: Hard coating (3H)
Reflection: No
Display Type: TN
Display Mode: White
Polarizer Type: Transmissive
Brightness: 400
Contrast: 500
Colors: 262000
Gray Scale: 6-bit
Gamut Percentage: 50
Color Gamut Type: NTSC
Left Viewing Angle: 70
Top Viewing Angle: 70
Right Viewing Angle: 70
Bottom Viewing Angle: 60
Optimal Viewing Direction: 6 o'clock
Chromaticity: 0.32
Chromaticity: 0.36
light uniformity: 1.25/1.33 (Typ./Max.)
(9 points)
Sunlight Readable: No
Reverse Scan: Yes
Reverse Scan Direction: Up/Down/Left/Right

Mechanical specs

Display Type: LCM
Size: 5.7
Aspect Ratio: 4 x 3
Shape: Flat Rectangle
Vertical Active Area: 86.4
Bezel Height: 89.4
Outline Vertical: 104.6
Outline Depth Max: 12.8000
Mounting: Rear mounting poles (4-Φ2.6)
Orientation: Vertical
Mounting Holes: Rear mounting poles (4-Φ2.6)

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 160
Typical Weight: 160
Maximum Weight: 160

Temperature Specs

Minimum Operating Temperature: -20
Maximum Operating Temperature: 70
Storage Temperature Minumum: -30
Storage Temperature Maximum: 85
