Innolux V390HK1-LF6 - TFT-LCD 1920 x 1080 Full HD

Product description

V390HK1-LF6 is a display manufactured by Innolux. It has a resolution of 1920 x 1080, brightness of 400 cd/m2 and contrast of 3500:1.

Electrical Specs

Backlight Location: Edge
Backlight: WLED
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Driver Board: With LED Driver
Minimum Voltage Driver Consumption: 22.8
Maximum Voltage Driver Consumption: 25.2
Minimum Backlight Consumption: 36.6
Maximum Backlight Consumption (Watts): 42.1
Backlight Connection: via Connector
Backlight Interface Manufacturer: CviLux
Backlight Interface Model: CI0114M1HR0-LA
Blu interface pin pitch mm: 2
Blu interface amount: 1
Blu interface pin amount: 14
Blu interface pin configuration: 0
Signal type: LVDS
Signal Channels: 4
Signal bits: 10-bit
VCC: 12
Maximum LCD Power Consumption: 6.9
Typical LCD Power Consumption: 5.2
Signal Interface: Connector
Signal Interface Manufacturer: FCN
Signal Interface Model: WF23-402-5133
LCD Signal Interface Pins Pitch (mm): 0.5
Signal Interface Connectors: 1
Signal Pins Quantity: 51

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.15
Dot pitch vertical: 0.44
Glare: Antiglare
Glare: 1
Reflection: No
Display Type: VA
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 400
Contrast: 3500
Gray Scale: 8-bit + Hi-FRC
Gamut Percentage: 68
Color Gamut Type: NTSC
Left Viewing Angle: 88
Top Viewing Angle: 88
Right Viewing Angle: 88
Bottom Viewing Angle: 88
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.28
Chromaticity: 0.29
light uniformity: 1.30 (Max.)
(5 points)
3D Type: 3D (Polarizer Glass)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 39
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 480.33
Bezel Height: 485.63
Outline Vertical: 501.63
Outline Depth Typical: 25.6
Outline Depth Max: 26.6000
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 7230
Typical Weight: 7230
Maximum Weight: 7230

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
