39" Inch TFT-LCD Display

V390HK1-LS6
Innolux

Home
TFT-LCD
Innolux
V390HK1-LS6

Innolux V390HK1-LS6 - TFT-LCD 1920 x 1080 Full HD

Product description

V390HK1-LS6 is a display manufactured by Innolux. It has a resolution of 1920 x 1080, brightness of 350 cd/m2 and contrast of 5000:1.

Electrical Specs

Vertical frequency hz input signal: 60
Vertical frequency hz display output: 120
Backlight Location: Edge
Backlight: WLED
Lamp Lifetime (Time to Half Brightness): 30000
Backlight Voltage Minimum: 34.7
Backlight Voltage Typical: 34.7
Backlight Voltage Maximum: 34.7
Backlight Current Minimum (mAh): 103.4
Backlight Current Typical (mAh): 110
Backlight Current Maximum (mAh): 116.6
Backlight Driver Board: With LED Driver
Minimum Voltage Driver Consumption: 22.8
Maximum Voltage Driver Consumption: 25.2
Minimum Backlight Consumption: 36.6
Maximum Backlight Consumption (Watts): 42.1
Backlight Connection: via Connector
Signal type: LVDS
Signal Channels: 2
Signal bits: 8-bit
VCC: 12
Maximum LCD Power Consumption: 8.74
Typical LCD Power Consumption: 7.34
Signal Interface: Connector

Optical specs

Panel type: TFT-LCD
Panel type child: a-Si
Resolution: 1920 x 1080
Dot Pitch: 0.15
Dot pitch vertical: 0.44
Glare: Antiglare
Glare: 1
Reflection: No
Display Type: VA
Display Mode: Black
Polarizer Type: Transmissive
Brightness: 350
Contrast: 5000
Colors: 16700000
Gray Scale: 8-bit
Gamut Percentage: 68
Color Gamut Type: NTSC
Left Viewing Angle: 88
Top Viewing Angle: 88
Right Viewing Angle: 88
Bottom Viewing Angle: 88
Optimal Viewing Direction: Symmetrical
Chromaticity: 0.28
Chromaticity: 0.29
light uniformity: 1.30 (Max.)
(5 points)
3D Type: 3D (Shutter Glass)
Sunlight Readable: No
Reverse Scan: No

Mechanical specs

Display Type: LCM
Size: 39
Aspect Ratio: 16 x 9
Shape: Flat Rectangle
Vertical Active Area: 480.33
Bezel Height: 485.63
Outline Vertical: 501.63
Outline Depth Typical: 25.6
Outline Depth Max: 26.6000
Orientation: Vertical

Sensory specs

Cover Lens: NoneNormal Cover GlassStandard CoverglassStrengthened CoverglassCover Lens
Touchscreen Type: NoneResistiveCapacitivePCAPEMBEDDED

Weights specs

Minimum Weight: 7100
Typical Weight: 7100
Maximum Weight: 7100

Temperature Specs

Maximum Operating Temperature: 50
Storage Temperature Minumum: -20
Storage Temperature Maximum: 60
